AT High Temperature PTFE Coated Fiberglass Cloth Tape

Description

AT High Temperature PTFE Coated Fiberglass Cloth Tape is made from tightly woven fiberglass cloth heavily coated with PTFE and finished with pressure-sensitive silicone adhesive on one side. It offers excellent high-temperature resistance, smooth release performance, weather resistance, anti-aging properties, and easy surface cleaning. Compared with acrylic adhesive versions, silicone adhesive provides a wider temperature range, making this tape suitable for heat sealing, roller wrapping, laminating, demoulding, insulation lining, and industrial surface protection where non-stick performance and thermal stability are required.

Key Features

• Wide Temperature Resistance: Performs reliably from -60°C to 260°C, with short-term resistance up to 300°C, making it suitable for high-temperature rollers, heating plates, and thermal processing equipment.
• Excellent Non-Stick Surface: PTFE-coated surface provides smooth release performance, helping prevent adhesion of oil, stains, melted materials, plastic films, and viscous substances.
• Weather and Aging Resistance: Fiberglass cloth backing with PTFE coating provides stable performance in harsh industrial environments, including heat, moisture, and long-term use.
• Flexible Silicone Adhesion: Pressure-sensitive silicone adhesive allows secure bonding to rollers, plates, liners, and machine surfaces while supporting high-temperature applications.

Applications

• Heat Sealing and Packaging Equipment: Used on heating plates, pressure bars, plastic film bag sealing machines, and food, dairy, or pharmaceutical packaging equipment.
• Roller and Laminating Machine Protection: Suitable for high-temperature roller wrapping, fine pressure roller coating machines, laminating surfaces, and thermoplastic release applications.
• Demoulding and Release Surfaces: Applied to off-membrane drums, thick liquid yarn machines, thermoplastic demoulding equipment, and other release-process surfaces.
• Industrial Lining and Insulation: Used as sliding channel liners, hopper liners, aviation mold liners, insulating liners, insulation encapsulation parts, and corrosion-resistant high-temperature surface protection.

Technical Specifications

Adhesive	Silicone
Adhesive Side	Single Sided
Adhesive Type	Pressure Sensitive
Backing Material	Glass Fiber Cloth
Surface Material	PTFE Coating
Color	Brown / Black
Liner	No
Thickness	0.13 mm / 0.18 mm / 0.25 mm
Short-Term Temperature Resistance	Up to 300°C
Long-Term Temperature Resistance	Up to 260°C
Operating Temperature Range	-60°C to 260°C
Roll Size	3” paper or plastic core; tape width: 2 mm–1200 mm; standard width: 1200 mm; standard length: 50 m
OEM Size	Custom length, thickness, width, roll, sheet, or die-cut shape available according to customer requirements or CAD drawings
Shelf Life	Use within 12 months from delivery; store at 16–27°C and 40–60% RH in the original carton



Customizable Options

• Thickness: Available in 0.13 mm, 0.18 mm, and 0.25 mm, with custom thickness options for different roller protection, heat sealing, and wear-resistance needs.
• Color: Brown and black options are available for different equipment identification, surface visibility, and process requirements.
• Width: Custom widths from 2 mm to 1200 mm can be supplied for narrow roller wrapping, machine surface lining, and wide-area protection.
• Length: Standard roll length is 50 m; special lengths can be supplied for production lines, distributors, and OEM packaging.
• Format: Available in rolls, sheets, strips, or die-cut shapes according to customer CAD drawings and application requirements.

Ordering & Technical Support

AxisTape provides flexible minimum order quantities, competitive pricing, and worldwide delivery. For custom specifications or technical inquiries, please feel free to contact us for a detailed consultation or email us at info@axistape.com.
