AT High Temperature Fabric Fiberglass Cloth Pure PTFE Film Tape

Description

AT High Temperature Fabric Fiberglass Cloth Pure PTFE Film Tape is a high-performance, multi-purpose solution made from imported fiberglass woven fabric and pure PTFE film coated with PTFE liquid. It delivers exceptional heat resistance, chemical stability, and low friction, making it ideal for applications in papermaking, food processing, textiles, pharmaceuticals, and electronics. Each roll typically measures 10 meters, providing reliable, durable protection for high-temperature industrial processes.

Key Features

• Exceptional Heat Resistance: Operates reliably from -70°C up to 300°C, suitable for high-temperature rollers, heat sealers, and industrial drying processes.
• Chemical and Corrosion Resistance: Strong resistance to acids and alkalis, ensuring durability in harsh chemical and food processing environments.
• Low Friction and High Stability: Minimizes wear and tear, providing smooth surface protection and preventing material sticking during industrial operations.
• Excellent Insulation and Safety: Non-toxic, food-grade, and fire-retardant properties make it safe for food processing and other sensitive applications.

Applications

• Packaging and Food Processing: Heat-resistant release surfaces for heat sealers, frozen food transport, and defrosting belts.
• Textile and Polymer Industries: Covers dryer cylinders, acts as lining and protective barriers for polymer processing, and supports industrial splicing and seaming of fluoropolymer materials.
• Industrial Rollers and Machinery: Suitable for high-temperature rollers and submerging applications requiring chemical and heat resistance.
• General Surface Protection: Provides reliable insulation and protection for various high-temperature, chemical, or industrial surfaces.

Technical Specifications

Adhesive	Silicone
Adhesive Side	Single Sided
Adhesive Type	Pressure Sensitive / Hot Melt
Material	Fiberglass Cloth + PTFE Film
Color	Brown
Thickness	0.06 – 0.13 mm
Roll Length	Typically 10 m
Roll Size	3” core; tape width: 2 mm – 1200 mm; standard width: 1200 mm, standard length: 50 m
OEM Size	Custom lengths, thicknesses, or shapes; rolls, sheets, or die-cut forms per CAD drawings
Temperature Resistance	-70°C to 300°C
Shelf Life	Use within 12 months from delivery; store at 16–27°C and 40–60% RH in original carton



Customizable Options

• Thickness: 0.06 mm to 0.13 mm for varying heat and surface protection needs.
• Width: 2 mm to 1200 mm to accommodate different rollers or surface areas.
• Length: Standard rolls 10 m; custom lengths available.
• Shape: Rolls, sheets, or die-cut forms according to CAD drawings.
• Material Composition: Options for varying PTFE coating or fiberglass density depending on industrial requirements.

Ordering & Technical Support

AxisTape provides flexible minimum order quantities, competitive pricing, and worldwide delivery. For custom specifications or technical inquiries, please feel free to contact us for a detailed consultation or email us at info@axistape.com.
