AT 244 High Temperature Automotive Masking Tape

Description

AT 244 High Temperature Automotive Masking Tape is a yellow paper masking tape designed for automotive painting, industrial spraying, and surface protection applications. Made with smooth paper backing and acrylic pressure-sensitive adhesive, it offers reliable adhesion, UV resistance, water resistance, and clean removal after use. The tape helps prevent paint bleed-through, supports sharp paint lines, and performs well on surfaces such as glass, flexible PVC, anodized aluminum, and painted substrates. It is suitable for automotive refinishing, marine masking, household appliance spraying, and other precision painting processes.

Key Features

• Enhanced UV Resistance: Provides strong sunlight stability, making it suitable for outdoor masking and applications requiring extended exposure before removal.
• Clean Removal After Use: Removes cleanly without adhesive transfer, even after prolonged use, helping reduce surface cleaning and rework.
• Paint Bleed-Through Resistance: The impregnated paper backing helps prevent paint infiltration, supporting sharp edges and professional paint finishes.
• Wide Surface Compatibility: Bonds well to glass, flexible PVC, anodized aluminum, painted surfaces, and other substrates commonly used in automotive and industrial painting.

Applications

• Automotive Painting and Refinishing: Used for car manufacturing, repair painting, high-end vehicle refinishing, and masking areas requiring clean paint edges.
• Marine and Outdoor Masking: Suitable for applications where UV resistance, water resistance, and clean removal are required during outdoor or marine painting work.
• Industrial Spray Painting: Applied in household appliances, interior decoration, cabinets, and other industrial coating processes.
• Electronics and PCB Masking: Can be used for wave solder masking and temporary protection of PCB areas where heat-resistant masking is required.

Technical Specifications

Adhesive	Acrylic
Adhesive Side	Single Sided
Adhesive Type	Pressure Sensitive
Material	Paper
Color	Yellow
Thickness	0.08 mm
Standard Size	Customized
Temperature Resistance	100°C for 30 minutes recommended; source table also indicates 60°C–300°C
Roll Size	3” paper or plastic core; tape width: 2 mm–1200 mm; standard width: 1200 mm; standard length: 50 m
OEM Size	Custom length, thickness, width, roll, sheet, or die-cut shape available according to customer requirements or CAD drawings
Shelf Life	Use within 12 months from delivery; store at 16–27°C and 40–60% RH in the original carton



Customizable Options

• Width: Available from 2 mm to 1200 mm for narrow trim masking, general painting, and wide-area surface protection.
• Length: Standard roll length is 50 m; custom lengths can be supplied for distributors, workshops, and industrial production lines.
• Thickness: Standard thickness is 0.08 mm; customized thickness can be provided according to masking strength and surface protection needs.
• Roll and Shape Format: Available in rolls, sheets, strips, or die-cut shapes based on customer CAD drawings or application requirements.
• OEM Packaging: Custom labeling, packaging, and private-label supply are available for automotive refinishing, industrial painting, and masking tape distributors.

Ordering & Technical Support

AxisTape provides flexible minimum order quantities, competitive pricing, and worldwide delivery. For custom specifications or technical inquiries, please feel free to contact us for a detailed consultation or email us at info@axistape.com.
