AT 06345 Perforated Trim Masking Tape 50.8 mm x 10 m

Description

AT 06345 Perforated Trim Masking Tape is designed for automotive refinishing and trim masking applications. Made with masking paper and pressure-sensitive acrylic adhesive, it features a rigid edge band that gently lifts vehicle moldings to allow paint to flow underneath, creating clean and concealed paint edges. The perforated structure enables manual tearing without tools, helping technicians improve painting efficiency while reducing the need to remove or replace existing trim parts.

Key Features

• Tool-Free Manual Tearing: Perforated design allows easy hand tearing, reducing preparation time and improving workflow during vehicle painting.
• Concealed Paint Edge Formation: The rigid edge band slightly lifts trim or plastic molding from the vehicle body, allowing paint to flow underneath for a cleaner, hidden finish.
• Reduced Trim Removal Cost: Helps avoid unnecessary removal, cleaning, or replacement of existing moldings, saving both labor time and material costs.
• Stable Removal and Accurate Placement: Strong backing supports one-piece removal, while the translucent liner helps technicians position the tape precisely around complex vehicle trim areas.

Applications

• Automotive Trim Masking: Used for side moldings, door handle inserts, taillight components, sidelights, headlight units, and other decorative trim areas.
• Windshield and Back Glass Protection: Applied around windshield and rear glass moldings to protect rubber strips and create concealed paint edges.
• Vehicle Repainting and Refinishing: Helps eliminate sharp paint edges, improves painting efficiency, and supports higher vehicle throughput in repair shops.
• Headlight and Exterior Part Protection: Can be used to protect headlights and adjacent vehicle surfaces during spray painting or refinishing without leaving adhesive residue.

Technical Specifications

Adhesive	Acrylic Adhesive
Adhesive Side	Single Sided
Adhesive Type	Pressure Sensitive
Material	Masking Paper
Color	White
Width	50.8 mm
Length	10 m
Temperature Resistance	-20°C to 100°C
Product Dimensions	10 x 7.3 x 7.3 inches
Roll Size	3” paper or plastic core; tape width: 2 mm–1200 mm; standard width: 1200 mm; standard length: 50 m
OEM Size	Custom length, thickness, width, roll, sheet, or die-cut shape available according to customer requirements or CAD drawings
Shelf Life	Use within 12 months from delivery; store at 16–27°C and 40–60% RH in the original carton



Customizable Options

• Width: Standard width is 50.8 mm; other widths can be supplied according to specific trim, molding, or body repair requirements.
• Length: Standard roll length is 10 m; custom roll lengths are available for workshop, distributor, or bulk packaging needs.
• Core and Roll Format: Available with 3” paper or plastic cores, with roll dimensions adjustable according to production and storage requirements.
• Material and Structure: Perforation spacing, liner style, backing strength, and rigid edge design can be adjusted for different automotive masking tasks.
• OEM Packaging: Custom labeling, packaging, and private-label supply can be arranged for automotive repair distributors and professional refinishing brands.

Ordering & Technical Support

AxisTape provides flexible minimum order quantities, competitive pricing, and worldwide delivery. For custom specifications or technical inquiries, please feel free to contact us for a detailed consultation or email us at info@axistape.com.
