PTFE Tape 3130MS
- High Temperature Resistance: With a wide operating temperature range from -80°C to 260°C, this tape is perfect for both high heat and low temperature environments.
- Strong Adhesion: Featuring a 7N/25mm peel strength, it provides a secure bond on various surfaces, ensuring reliable performance in critical applications.
- Durability and Flexibility: Weighing 240g/m² with a thickness of 0.13mm, this tape combines strength and flexibility to meet industrial needs.
- Ideal for Harsh Environments: With its temperature resistance and robust design, the tape performs well in industries that involve high-temperature sealing and insulation.
Free shipping on orders over $50!
- Satisfaction Guaranteed
- No Hassle Refunds
- Secure Payments
Description
PTFE Tape 3130MS is a premium PTFE film tape designed for demanding industrial applications. Made with a 0.05mm silicone adhesive and 0.13mm PTFE film, this tape provides exceptional performance in high-temperature environments. Its excellent wear resistance and strong adhesion make it ideal for sealing, insulation, and protective applications.
Technical Specifications
| Color | Grey |
| Length | 10M |
| Width | 500mm |
| Finished Product Thickness | 0.13mm |
| Finished Product Weight | 240g/m² |
| Peel Strength (90°TEST) | ≥7N/25mm |
| Adhesive Thickness | 0.05mm |
| Long term temperature resistance | (-80~260℃) |
Standards Compliance
Tested according to GB/T7689.1, ASTM D4851-88, and GB/T2423.1 to ensure consistent performance and reliability.
Key Features
- High Temperature Resistance: With a wide operating temperature range from -80°C to 260°C, this tape is perfect for both high heat and low temperature environments.
- Strong Adhesion: Featuring a 7N/25mm peel strength, it provides a secure bond on various surfaces, ensuring reliable performance in critical applications.
- Durability and Flexibility: Weighing 240g/m² with a thickness of 0.13mm, this tape combines strength and flexibility to meet industrial needs.
- Ideal for Harsh Environments: With its temperature resistance and robust design, the tape performs well in industries that involve high-temperature sealing and insulation.
Applications
- Sealing & Insulation: Ideal for sealing electrical systems, machinery, and high-temperature components.
- Electrical: Widely used for electrical insulation in wiring and sensitive components exposed to heat and stress.
- Automotive: Perfect for automotive applications that require sealing or insulation against high temperatures.
- Industrial Use: Ideal for use in manufacturing processes, machinery protection, and any industrial application requiring high-performance sealing.
Structure
Customizable Options
At AxisTape, we offer the PTFE Tape 3130MS in a variety of sizes and thicknesses to suit your specific needs:
- Widths & Lengths: Custom cuts are available to meet project specifications.
- Color Options: Standard gray color, with the option for custom colors.
- Adhesion Strength: Tailored adhesion options are available for specific applications.
Storage Recommendations
For optimal performance, store PTFE Tape 3130MS in a dry, indoor environment with temperatures ranging from 5°C to 30°C. Avoid exposure to direct sunlight, extreme temperatures, and high humidity to preserve its integrity.
Ordering & Technical Support
AxisTape provides flexible minimum order quantities, competitive pricing, and worldwide delivery. For custom specifications or technical inquiries, please feel free to contact us for a detailed consultation or email us at info@axistape.com.
