AT Grey Automotive Acrylic Foam Die-cut Tape

Description

AT Grey Automotive Acrylic Foam Die-cut Tape is designed for automotive exterior and interior attachment applications requiring strong adhesion, stress relaxation, and long-term durability. Made with grey acrylic foam and double-sided acrylic pressure-sensitive adhesive, it provides high peel strength, shear resistance, good conformability, and reliable bonding to a wide range of automotive surfaces. The foam core helps absorb stress and maintain a stable bond line under load. AxisTape can supply this material in rolls, strips, sheets, or custom die-cut shapes for automotive trim, door handles, wheel arcs, signs, metal plaques, safety glass, and other vehicle components.

Key Features

• Automotive Acrylic Foam Structure: The grey acrylic foam core provides conformability, internal strength, and stable bonding performance for automotive attachment applications.
• High Peel and Shear Adhesion: The acrylic adhesive system supports strong bonding to automotive trim parts, metal plaques, signs, panels, and component surfaces.
• Stress Relaxation Under Load: The viscoelastic foam structure helps disperse stress at the bond line, reducing localized stress concentration during use.
• Excellent Plasticizer Resistance: The tape is suitable for bonding selected automotive plastics and trim materials where plasticizer resistance is required.
• Heat and Weather Resistance: The material provides heat-resistant and durable bonding performance for automotive exterior and interior applications.
• Precision Die-cut Processing: AxisTape can process the tape into strips, pads, holes, frames, tabs, and irregular shapes according to customer drawings or samples.

Applications

• Automotive Trim Strips: Used for attaching front trim strips, rear trim strips, side moldings, and decorative automotive parts.
• Door Sill and Door Handle Components: Suitable for bonding door sill strips, door handles, protective strips, and related vehicle accessories.
• Wheel Arcs and Anti-collision Strips: Applied to wheel arc parts, corner anti-collision strips, baffles, rear guards, and exterior protective components.
• Metal Plaques and Vehicle Signs: Suitable for automobile and motorcycle signs, metal nameplates, badges, and decorative labels.
• Safety Glass and Auto Parts: Used for bonding and fixing selected safety glass components, automotive parts, and assembly accessories.
• Custom Die-cut Automotive Tape Parts: Suitable for custom adhesive pads, frame shapes, pull-tab designs, holes, slots, kiss-cut sheets, and roll-format die-cut parts.

Technical Specifications

Adhesive	Acrylic
Adhesive Type	Pressure sensitive
Color	Grey / gray
Size	Customized
Nominal Thickness	0.8 mm, based on the source product page. If benchmarking against 4229P-type specifications, 0.76 mm may be referenced separately and should be confirmed before production.
Temperature Resistance	150°C
Adhesion to 304 Steel Plate	51 N/100 mm
Roll Size	3 in paper or plastic core; tape width 2-1200 mm; standard width 610 mm; standard length 36 yd
OEM Size / Processing	Special length, thickness, or combinations can be supplied per customer request. Products can be supplied in rolls, tapes, sheets, or custom die-cut shapes according to CAD drawings.
Shelf Life	12 months from date of delivery under recommended storage conditions
Recommended Storage	Store in the original carton at 60-80°F / 16-27°C and 40-60% RH. The source page appears to contain a unit typo; this row uses the normalized Fahrenheit/Celsius range.



Customizable Options

• Custom Shape and Size: The tape can be die-cut into strips, pads, frames, rings, holes, tabs, slots, and irregular profiles according to CAD drawings, samples, or assembly dimensions.
• Thickness and Width Options: Standard page data indicates 0.8 mm nominal thickness; width, length, and die-cut geometry can be customized according to bonding area and application requirements.
• Adhesive and Liner Options: Double-sided acrylic pressure-sensitive adhesive is available; release liner type, adhesive coverage, and die-cut release format can be adjusted for manual or automated assembly.
• Supply Format: Products can be supplied in rolls, tapes, sheets, individual die-cut pieces, kiss-cut sheets, or roll-format die-cut components.
• Application-based Converting: Slitting, laminating, sheet cutting, hole cutting, kiss cutting, tab design, tolerance control, and packaging format can be customized for automotive attachment projects.

Ordering & Technical Support

AxisTape provides flexible minimum order quantities, competitive pricing, and worldwide delivery. For custom specifications or technical inquiries, please feel free to contact us for a detailed consultation or email us at info@axistape.com.
