AT White 2.0mm Acrylic Foam Die-cut Dot

Description

AT White 2.0mm Acrylic Foam Die-cut Dot is designed for permanent bonding, mounting, cushioning, gap filling, and sealing applications where a clean white foam dot is required. Made from firm white acrylic foam with double-sided acrylic pressure-sensitive adhesive, it provides strong adhesion, stress relaxation, vibration damping, and reliable bonding to high surface energy substrates such as metal, glass, painted surfaces, panels, signs, and selected plastics. AxisTape can supply this material as round dots, discs, pads, squares, rings, strips, or custom die-cut shapes according to customer drawings, samples, bonding area, and assembly requirements.

Key Features

• 2.0mm White Acrylic Foam Structure: The 2.0mm firm acrylic foam structure provides thickness, cushioning, and stable bonding support for mounting and assembly applications.
• Double-sided Acrylic Adhesive: Acrylic pressure-sensitive adhesive on both sides supports strong bonding to high surface energy substrates such as metal, glass, painted surfaces, signs, and panels.
• Permanent Bonding Performance: The foam dot is suitable for long-term attachment applications where screws, rivets, welding, or liquid adhesive may not be preferred.
• Stress Relaxation and Vibration Damping: The viscoelastic foam structure helps absorb stress, reduce vibration, and improve bonding stability under load.
• Clean White Appearance: The white foam structure is suitable for applications requiring a clean adhesive appearance, especially for signs, displays, panels, decorative parts, and appliance components.
• Precision Die-cut Processing: AxisTape can process the material into dots, discs, rings, pads, strips, squares, holes, tabs, and irregular shapes based on CAD drawings or samples.

Applications

• Signs and Nameplates: Used for mounting signs, nameplates, logos, badges, decorative overlays, and identification plates.
• Display and Panel Assembly: Suitable for bonding display panels, decorative panels, frame parts, cover plates, and thin structural components.
• Appliance Components: Applied in household appliance logos, control panels, trims, stiffeners, and decorative attachment parts.
• Electronics and Industrial Assembly: Used for mounting electronic components, equipment panels, industrial parts, and general assembly structures.
• Gap Filling and Cushioning: Suitable for applications requiring both bonding and foam thickness to fill small gaps, absorb vibration, or reduce contact stress.
• Custom Die-cut Foam Dots: Designed for custom round dots, square pads, rings, tabs, kiss-cut sheets, roll-format die-cut dots, and adhesive parts based on customer drawings.

Technical Specifications

Foam Type	Firm acrylic foam, closed-cell structure
Adhesive Type	General-purpose acrylic pressure-sensitive adhesive
Color	White
Nominal Thickness	2.0 mm / 0.080 in / 80 mil
Release Liner	PET release liner; liner color and release force can be customized
Target Bonding Surfaces	High surface energy substrates such as metal, glass, painted surfaces, selected plastics, panels, signs, and equipment surfaces
Temperature Performance	Designed for indoor and outdoor bonding applications; benchmark material data indicates long-term temperature resistance up to about 149°C / 300°F and short-term exposure up to about 204°C / 400°F. Final values should be confirmed by project testing.
Die-cut Shapes	Dots, discs, circles, squares, rectangles, strips, pads, rings, holes, tabs, frames, and irregular shapes
Custom Size	Diameter, length, width, inner hole, liner format, spacing, and sheet/roll layout can be customized according to CAD drawings or samples
Supply Format	Individual die-cut pieces, kiss-cut sheets, rolls, strips, or custom roll-format die-cut parts



Customizable Options

• Custom Shape and Size: The tape can be die-cut into round dots, discs, square pads, rectangular pads, rings, strips, holes, tabs, frames, and irregular profiles according to CAD drawings or samples.
• Thickness and Diameter Options: Standard product positioning is 2.0mm nominal thickness. Dot diameter, pad size, inner hole, spacing, and sheet or roll layout can be customized according to bonding area and assembly method.
• Adhesive and Liner Options: Double-sided acrylic pressure-sensitive adhesive is available; PET liner, release force, liner color, liner size, and easy-peel tab design can be adjusted for manual or automated assembly.
• Supply Format: Products can be supplied as individual pieces, kiss-cut sheets, roll-format die-cut dots, strips, pads, or customized adhesive components.
• Application-based Converting: Slitting, laminating, sheet cutting, hole punching, kiss cutting, half cutting, through cutting, spacing control, and packaging format can be customized for production requirements.

Ordering & Technical Support

AxisTape provides flexible minimum order quantities, competitive pricing, and worldwide delivery. For custom specifications or technical inquiries, please feel free to contact us for a detailed consultation or email us at info@axistape.com.
