AT White/Translucent Silicone Foam Gasket for Condensation Seal

Description

AT White/Translucent Silicone Foam Gasket for Condensation Seal is a custom die-cut sealing solution made from flexible silicone foam with single-sided acrylic pressure-sensitive adhesive. Designed for condensation sealing, cushioning, insulation, and masking applications, it offers good compression recovery, heat resistance, low-temperature flexibility, and stable chemical performance. The material can be supplied in rolls, sheets, strips, or precision die-cut shapes according to customer drawings. AxisTape supports custom gasket dimensions, hole positions, thicknesses, and adhesive layouts, making this product suitable for electronics, industrial equipment, home appliances, and other applications requiring reliable sealing and protection.

Key Features

• Heat and Temperature Resistance: Silicone foam provides stable performance under high and low temperature conditions, making it suitable for demanding sealing and insulation applications.
• Flexible and Compressible Structure: The soft foam structure helps absorb pressure, fill gaps, and maintain sealing performance on uneven or irregular surfaces.
• Single-sided Pressure-sensitive Adhesive: The acrylic adhesive backing allows easy positioning and bonding during assembly, reducing the need for additional fixing methods.
• Electrical Insulation and Chemical Stability: Silicone foam offers good insulation properties and stable chemical resistance, supporting use in electronic, industrial, and appliance-related applications.
• Precision Die-cut Capability: AxisTape can process the material into custom shapes, holes, strips, pads, or gasket designs based on CAD drawings, samples, or dimensional requirements.

Applications

• Condensation Sealing: Used as a sealing gasket in equipment, panels, housings, and components where moisture or condensation control is required.
• Electronic Assembly: Suitable for cushioning, insulation, gap filling, and protective sealing in electronic devices and components.
• Industrial Equipment: Applied in machinery, control panels, enclosures, and other industrial parts requiring heat-resistant foam sealing.
• Home Appliance Components: Used for sealing, buffering, and insulation in appliance assemblies where soft, compressible gasket materials are needed.
• Masking and Protection: Can be used in selected masking, spacing, and protective applications where silicone foam and pressure-sensitive adhesive are required.

Technical Specifications

Material	Silicone foam
Adhesive	Acrylic pressure-sensitive adhesive
Adhesive Side	Single sided
Color	White / translucent appearance
Thickness	0.5-10 mm, customizable according to drawings or application requirements
Size	Customized size, shape, hole position, and layout available
Roll Size	3-inch paper or plastic core; available tape width: 2-1200 mm; standard width: 1200 mm; standard length: 50 m
Supply Format	Rolls, strips, sheets, kiss-cut parts, or individual die-cut shapes
Feature	Heat-resistant, flexible, compressible, insulating, pressure-resistant, and chemically stable
Application Focus	Condensation sealing, cushioning, insulation, masking, electronic assembly, and industrial sealing
Design Printing	No printing by default; custom marking or liner printing can be discussed if required
Shelf Life	Use within 12 months from delivery date when stored in the original carton under normal conditions
Recommended Storage	60-80°F / 16-27°C and 40-60% RH, away from direct sunlight, high humidity, dust, and contamination



Customizable Options

• Custom Shape and Size: Gaskets can be produced according to CAD drawings, samples, or customer-provided dimensions, including special shapes, holes, slots, and positioning structures.
• Thickness and Material Format: Available in customizable thickness from 0.5 mm to 10 mm, with supply formats including rolls, sheets, strips, pads, and individual die-cut parts.
• Adhesive and Liner Options: Single-sided acrylic adhesive is available by default; liner type, release performance, and adhesive layout can be adjusted according to application requirements.
• Packaging and Delivery Format: Products can be supplied as individual pieces, kiss-cut sheets, roll-format die-cut parts, or bulk-packed components for manual or automated assembly.

Ordering & Technical Support

AxisTape provides flexible minimum order quantities, competitive pricing, and worldwide delivery. For custom specifications or technical inquiries, please feel free to contact us for a detailed consultation or email us at info@axistape.com.
