PTFE Tape 3180MS
- Excellent Temperature Resistance: With a wide operational range from -40°C to 260°C, PTFE Tape 3180MS performs exceptionally well in both low and high-temperature environments, making it suitable for a variety of industrial uses.
- Strong Adhesion: The tape provides a robust ≥6N/25mm peel strength on stainless steel, ensuring a secure and reliable bond even under difficult conditions.
- Heavy-Duty Construction: Featuring a finished product weight of 350g/m² and 0.18mm thickness, this tape provides durability while maintaining flexibility for easier application.
- High Initial Adhesion: It meets the Steel Ball No. 19 adhesion standard, ensuring strong immediate bonding capabilities.
Free shipping on orders over $50!
- Satisfaction Guaranteed
- No Hassle Refunds
- Secure Payments
Description
PTFE Tape 3180MS is a versatile and durable tape designed for use in high-temperature and industrial environments. Made from a 0.18mm PTFE film and a 0.05mm silicone adhesive, this tape offers exceptional resistance to heat, wear, and chemicals. Its superior bonding strength makes it ideal for insulation, sealing, and other demanding industrial applications.
Technical Specifications
| Length | 10M |
| Width | 500mm |
| Finished Product Thickness | 0.18mm |
| Initial Adhesion (30° Test) | ≥ Steel Ball No. 19 |
| Finished Product Weight | 350g/m² |
| Peel Strength (90°TEST) | ≥6N/25mm |
| Adhesive Thickness | 0.05mm |
| Long term temperature resistance | (-40~260℃) |
Standards Compliance
Tested according to GB/T7689.1, ASTM D4851-88, and GB/T2423.1, ensuring consistent performance and reliability in industrial applications.
Key Features
- Excellent Temperature Resistance: With a wide operational range from -40°C to 260°C, PTFE Tape 3180MS performs exceptionally well in both low and high-temperature environments, making it suitable for a variety of industrial uses.
- Strong Adhesion: The tape provides a robust ≥6N/25mm peel strength on stainless steel, ensuring a secure and reliable bond even under difficult conditions.
- Heavy-Duty Construction: Featuring a finished product weight of 350g/m² and 0.18mm thickness, this tape provides durability while maintaining flexibility for easier application.
- High Initial Adhesion: It meets the Steel Ball No. 19 adhesion standard, ensuring strong immediate bonding capabilities.
Applications
- Sealing & Insulation: Ideal for sealing and insulating electrical components, machinery, and high-temperature parts.
- Electrical: Widely used for wire insulation and protecting sensitive electrical components exposed to heat and stress.
- Automotive & Manufacturing: Perfect for automotive and industrial applications that require high performance under extreme conditions.
- Protection in Harsh Environments: Its durability makes it ideal for protecting equipment exposed to fluctuating temperatures, chemicals, and mechanical wear.
Structure
Customizable Options
At AxisTape, we offer PTFE Tape 3180MS in various sizes and thicknesses to meet specific requirements:
- Widths & Lengths: Custom cut to size for your project specifications.
- Adhesion Strength: Tailored adhesion strengths are available for various bonding needs.
- Colors: The standard color is gray, but custom colors can be produced on request.
Storage Recommendations
For optimal performance, store PTFE Tape 3180MS in a dry, indoor environment with a temperature range of 5°C to 30°C. Avoid exposure to direct sunlight, high humidity, and extreme temperatures.
Ordering & Technical Support
AxisTape provides flexible minimum order quantities, competitive pricing, and worldwide delivery. For custom specifications or technical inquiries, please feel free to contact us for a detailed consultation or email us at info@axistape.com.
