AT Black Conductive Foam Die-cut Pad

Description

AT Black Conductive Foam Die-cut Pad is a self-adhesive conductive foam solution designed for EMI shielding, grounding contact, and interference isolation in electronic products. The material combines conductive foam with a conductive cloth-wrapped sponge structure and conductive acrylic pressure-sensitive adhesive, offering good electrical conductivity, flexibility, and stable contact performance. It can be applied to computers, mobile phones, wires, cables, circuit boards, transformers, home appliances, and other electronic assemblies. AxisTape can supply this product in customized widths, sizes, pads, sheets, strips, or precision die-cut shapes according to customer drawings and shielding requirements.

Key Features

• Good Electrical Conductivity: The conductive foam structure helps create stable electrical contact for EMI shielding, grounding, and interference isolation applications.
• Flexible Urethane Foam Structure: The foam base provides good flexibility and stability, allowing the pad to conform to uneven surfaces and maintain contact pressure.
• Conductive Adhesive Backing: The single-sided conductive acrylic adhesive allows the foam pad to be fixed easily onto shielding devices, housings, panels, and electronic components.
• EMI Shielding Support: The material is suitable for high-frequency electromagnetic shielding and isolation in computers, mobile phones, cables, and other electronic products.
• Custom Die-cut Processing: AxisTape can provide special cutting, half-cutting, hole cutting, oversized pull tabs, and custom shape processing based on CAD drawings or samples.

Applications

• Computers and Mobile Devices: Used for EMI shielding, grounding, conductive contact, and interference isolation in computers, mobile phones, tablets, and compact electronic products.
• Wires and Cables: Suitable for shielding or isolating interference around wire and cable assemblies in high-frequency signal environments.
• Circuit Boards and Transformers: Applied to circuit boards, transformers, electronic modules, and internal components requiring conductive foam contact or protection.
• Home Appliances and Electronic Products: Used in home appliances, control systems, electronic housings, and assembled devices requiring EMI suppression or conductive cushioning.
• Custom Die-cut Shielding Parts: Suitable for custom conductive foam pads, sheets, holes, oversized pull-tab designs, half-cut formats, and special shapes for faster assembly.

Technical Specifications

Adhesive	Conductive acrylic adhesive
Adhesive Type	Pressure-sensitive adhesive
Color	Black
Width	Customized size
Size	Customized size according to drawings, samples, or application requirements
Thickness	0.025 mm-30 mm available depending on material structure and application requirement
Adhesive Strength	>1000 gf/25 mm
Holding Strength	>3600 sec
Surface Resistance	0.2 Ω/sq; 1.0 Ω/in max
Volume Resistance	0.2 Ω/sq
Top-bottom Resistance	1.0 Ω/in max



Customizable Options

• Custom Shape and Size: Conductive foam pads can be processed into strips, sheets, pads, holes, rings, frames, oversized pull-tab designs, or irregular shapes according to CAD drawings or samples.
• Thickness and Material Structure: Thickness can be selected within the available range according to shielding performance, compression requirement, gap height, and assembly design.
• Conductive Layer Options: Material structures can be adjusted using conductive cloth, aluminum foil cloth, conductive fiber cloth, plated fabric, or other conductive surface layers according to the application.
• Delivery Format: Products can be supplied as sheets, rolls, individual die-cut pieces, kiss-cut sheets, half-cut parts, or slitted strips for manual or automated assembly.

Ordering & Technical Support

AxisTape provides flexible minimum order quantities, competitive pricing, and worldwide delivery. For custom specifications or technical inquiries, please feel free to contact us for a detailed consultation or email us at info@axistape.com.
